UR(A)B_LD-30WR3 series product output power is 30W,4:1 wide voltage input range,efficiency up to 91%,conversional isolation volatge of 1500VDC,allowable operating temperature is -40℃to+85℃,
with input under-voltage protection, output over-voltage, over-current,short-circuit protection function, bare metal meets CISPR32/EN55032CLASSA , widely used in medical, industrial control, electri power, instrumentation,communication, railway and other fields.
Wide input voltage range(4:1),Output 30W
Conversion efficiency91%(Typ)
Isolation voltage 1500Vdc
Ultra low power consumption:0.036W(Typ)
Fast startup:1ms(Typ)
Working temperature range:-40°C~+85℃
Input undervoltage , output short circuit , overcurrent,overvolatge protection
Metal case,low output ripple
International standard pins,PCB board in-line
Enviroment Condition
Project name
Qualification
Unit
Notes
Working enviroment temperature
-40—+85
℃
Storage temperture
-40—+80 ℃
℃
Relative humidity
5—95
%
Heat dissipation mode
natural cooling
Atmospheric pressure
80—106 Kpa
Kpa
Vibrate
Vibration coefficient 10~500Hz,2G10min./1cycle, 60min.each along X,Y,Z axes
Meet the requirements of secondary road transportation
Input Characteristics
Project name
Working conditions
Unit
Notes
Related input voltage
48
Vdc
Input voltage range
18-75
Vdc
Maximum input current
≤1.45
A
Reflected ripple
Nominal input voltage 40
mA
DC 5V rated input voltage series
Impulse voltage
≤100
Vdc
Starting voltage
18
Vdc
Input undervoltage protection
12-15.5
Vdc
Start-up delay
1
ms
Rated input voltage and constant resistance load
Input filter type
PI version
Hot plugged
Non-support
Output Characteristics(5V/6000mA)
Project name
Technical requirement
Unit
Notes
No load rated output voltage
5V±2%
Vdc
Short-time maximum output current
≥6000
mA
Rated output current
5900
mA
Voltage regulation
±0.5
%
Load regulation
±0.5
%
Transfer efficiency
Vin=5Vdc, output full load 90
%
Output ripple and noise (mVp-p)
Pure resistive load, 20MHz bandwidth, peak to peak
mV
Output over-current protection
the maximum load 110-200%
Vdc
Insulation voltage
Input- output, test in 1 minute, leakage current less than 1mA/1500V
-
Insulation resisitance
Input- output, insulation volaltge 500VDC/1000MΩ
MΩ
Isolation capacitance
Input- output, 100KHz/0.1V 1000pF
-
Note:
(1) For product model with output voltage ±5VDC or ±9VDC , the maximum output voltage accuracy is ±5% under 0% - 5% load condition
(2) When tested according to the 0%-00% load working condition, the load adjustment rate is ±5%
(3) 0%-5% load ripple & noise less than or equal to 5% Vo. Ripple and noise test method, Twisted pair test method, can add capacitive load at the output to reduce light load ripple
Typical Application Circuits
EMC parameter recommendation
Component No.
24V Input Product
48V Input Product
110V Input Product
FMSE Fuse
Access the corresponding fuse accrding to customer needs
MOV/Varistor
14D560K
14D101K
14D201K
LDM1/Common mode inductance
10mH
15mH
30mH
CO,C1 Ceramic capacitors
100μF/50V
100μF/100V
100μF/200V
E1,E2 Electrolytic capacitor
1μF/50V
1μF/100V
0.47μF/250V
LDM2/Differential mode inductance
10μH
15μH
68μH
CY1/Y2 Capacitance
1nF/250vAC
Notes:
* Fuses and varistors are basic parts of protection circuits (required).
* If the certification is required, the safety capacitor and common mode inductance cannot be omitted.
