E05xxS-1WR3 E0524S-1WR3
型号
E0503S-1WR3
E0505S-1WR3
E0509S-1WR3
E0512S-1WR3
E0515S-1WR3
E0524S-1WR3
促销
DC to DC power module:
1W: https://drive.google.com/drive/folders/1vk6luTBKSC5gfwLJC-DbyEZYVDwk87JV
2W: https://drive.google.com/drive/folders/1vjf-77LCVQl16Hcb1phADiU3Hz14mhYB
3W: https://drive.google.com/drive/folders/13pTx02uL4moskJ-PQsBYFytdq2pPt2mN
5W: https://drive.google.com/drive/folders/1okF0YdP1Xs35HxnAkTm45WOK0kH7qlb5?
6W: https://drive.google.com/drive/folders/18IOw7PyIx99lbm3u0FEhkepC82w601sw
10W: https://drive.google.com/drive/folders/1vuJp5ZoJA9Ci0M4wCS8nT689LVzgh2tC
12W: https://drive.google.com/drive/folders/1becUdxQODQ25_A_iarNnun3Vmi_wow1g
20W: https://drive.google.com/drive/folders/182aHyvoN8J0fCurg65jOkfQp17dyaXP6
30W: https://drive.google.com/drive/folders/1StP-0SJDyFpH3yQMLLQjkQXMDXc-RGeP
40W: https://drive.google.com/drive/folders/1IXRm7dueYYTNoyXCFp88wRQexmKAgCLm
B0505S-1WR2: https://drive.google.com/file/d/16BPrOWkzOz7efnf3OvF1XjClKGnO6znv/view
AC to DC power module:
https://drive.google.com/drive/folders/1HcZhdzhKA4p08B_YEv_A6sUOvNJ0Ei9n?usp=sharing
Product Features:
5Pin SIP international standard pin
Isolation voltage: 3000VDC
High conversion efficiency, up to 89%
Low ripple coefficient and low noise
Working environment temperature: -40 ℃~+85 ℃
MTBF ≥ 3.5 million hours (3500000 Hrs)
Output short circuit protection: sustainable short circuit protection, automatic recovery
Built in soft start technology
Special specification products can be designed according to customer needs
Input characteristic:
Item Working Conditions Min. Typ. Max. Unit 3.3VDC input series -- 370/3 --/15 5VDC input series -- 235/3 --/15 Input voltage range 12VDC input series -- 99/3 --/15 Vdc 15VDC input series -- 99/3 --/15 24VDC input series -- 51/3 --/15 Reflected ripple current -- 15 -- Impulse Voltage
3.3VDC input series -0.7 -- 5 Vdc 5VDC input series -0.7 -- 9 12VDC input series -0.7 -- 18 15VDC input series -0.7 -- 21 24VDC input series -0.7 -- 30 Input fliter typle Capacitive filtering
Hot plug Non-support
Output characteristic:
Item Working and testing condition Min. Typ. Max. Unit Output load load percentage 10 -- 100 % Output Voltage Accuracy -- -- ±15.0 % Linear adjustment rate Input voltage variation ±1% 3.3V output -- -- ±1.5 % others -- -- ±1.2 % Load adjustment rate 10%~100% load 3.3VDC output -- 10 -- % 5VDC output -- 8 -- % 9VDC output -- 8 -- % 12VDC output -- 7 -- % 15VDC output -- 6 -- % 24VDC output -- 6 -- % Ripple & Noise Pure resistive load, 20HMz bandwidth, peak-to-peak -- 45 100 mVp-p Temperature Drift Coefficient Full load -- -- ±0.03 %/℃ Output short circuit protection Continuous short circuit protection, automatic recovery Notes: Ripple and Noise Test Methods Twisted Pair Test Method
General characteristic:
Item Working condition Min. Typ. Max. Unit Insulation voltage Input output, test time of 1 minute, leakage current less than 1mA 3000 -- -- VDC Insulation resistance Input output, insulation voltage 500VDC 1000-M Ω 1000 -- -- MΩ Isolation capacitor Input output, 100KHz/0.1V --40-- pF -- 20 -- pF Working temperature Use reference temperature derating curve chart -40 -- +85 ℃ Storage temperature -40 -- +125 Temperature rise of the casing during operation -- 25 -- Storage humidity No condensation 5 -- 95 %RH Pin resistance to welding temperature Welding point distance from the shell 1.5mm, 10 seconds -- -- +300 ℃ Switching frequency Full load, nominal voltage input -- 100 -- KHz Shock 10-55Hz, 10G, 30 Min. along X, Y and Z Shell material Black flame retardant and heat-resistant plastic (UL94V-0) Minimum time between failures MIL-HDBK-217F@25℃ 3.5X10 6 -- -- Hrs
