HLK-60SR12 HLK-60SR12 --EngrWorld

	Type	Description
	Product type	AC-DC module
	Manufacturer	Shenzhen Hi-Link
	Brand	Hi-Link
	Universal package	Module Package
	Transfer type	AC-DC Isolated Power Module
	Conversion efficiency	≥87%
	Operation voltage (AC)	85-265VAC (nominal: 100-240VAC)
	Operation voltage (DC)	120-350VDC
	Output voltage （Vout)	12V
	Output current	5000mA
	Output power	60W
	Isolation voltage (Vrms)	3000VAC
	Max capacitive load	≤1500μF
	Package	Full-module potting encapsulation
	Operating temperature	-25℃ ~ +40℃
	Size	57.5×33.5×28mm

Shopping guide

Ladder price

Qty.	Unit price	Total price
1+	$6.60	$6.60

Total inventory

Out of stock

Purchase quantity

MOQ:1 Increment:1

Total price：

Add to wish list

Share link

Service declaration

SHIPPING WAYS

Supports seven days of returns without reason

If the delivery is lost, return is supported

If the delivery is damaged, return is supported

Free exchange within 90 days

Security and privacy

Secure Payment: We will not share your personal information with any third party without your consent.

Secure Personal data: We protect your privacy and ensure that your personal data is safe and secure.

Payment security

With a popular payment partner, your personal information is safe.

Project name	Technical standard	Unit	Remark
Working Temerature	-25—+40	℃
Storage temperature	-40—+80	℃
Relative humidity	5—95	%
Thermal methods	Natural cooling
Atmospheric pressure	80—106	Kpa
Altitude	≤2000	m
Vibration coefficient	10~500Hz,2G10min./1cycle, 60min.each along X,Y,Z axes		Meets requirements for secondary road transportation

Project name	Technical requirement	Unit	Remark
No load rated output voltage	5+0.2	vdc
Full-load rated output voltage	5±0.2	vdc
Short term maximum output current	≥10200	mA
Output current	10000	mA
Voltage regulation	士0.2	%
Load Regulation	士0.5	%
Input low voltage efficiency	Vin=115Vac， Output full load>84	%
Input high voltage efficiency	Vin=230Vac，output full load>85	%
Output ripple and noise (mVp-p)	≤100 Rated input voltage, output at full load. Use a 20MHz bandwidth oscilloscope to test the load end with 47uF and 0.1uF capacitors.	mV
Output over-current protection	Output 130-180% of maximum load	A
Short Circuit Protection	Short circuit directly during normal output, and automatically resume normal operation after the short circuit is removed		Do not damage the entire machine

Project name	Technical requirement	Unit	Remark
No load rated output voltage	9+0.2	vdc
Full-load rated output voltage	9±0.2	vdc
Short term maximum output current	≥6860	mA
Output current	6660	mA
Voltage regulation	士0.2	%
Load Regulation	士0.5	%
Input low voltage efficiency	Vin=115Vac， Output full load>86	%
Input high voltage efficiency	Vin=230Vac，output full load>88	%
Output ripple and noise (mVp-p)	≤100 Rated input voltage, output at full load. Use a 20MHz bandwidth oscilloscope to test the load end with 47uF and 0.1uF capacitors.	mV
Output over-current protection	Output 130-180% of maximum load	A
Short Circuit Protection	Short circuit directly during normal output, and automatically resume normal operation after the short circuit is removed		Do not damage the entire machine

Project name	Technical requirement	Unit	Remark
No load rated output voltage	12+0.2	vdc
Full-load rated output voltage	12±0.2	vdc
Short term maximum output current	≥5200	mA
Output current	5000	mA
Voltage regulation	士0.2	%
Load Regulation	士0.5	%
Input low voltage efficiency	Vin=115Vac， Output full load>86	%
Input high voltage efficiency	Vin=230Vac，output full load>88	%
Output ripple and noise (mVp-p)	≤100 Rated input voltage, output at full load. Use a 20MHz bandwidth oscilloscope to test the load end with 47uF and 0.1uF capacitors.	mV
Output over-current protection	Output 130-180% of maximum load	A
Short Circuit Protection	Short circuit directly during normal output, and automatically resume normal operation after the short circuit is removed		Do not damage the entire machine
