HLK-N10 HLK-N10 --EngrWorld

HLK-N10 is an industrial-grade NB-IoT wireless communication module, which is fully compatible with R13 and R14 in terms of protocols, and supports R15 through software upgrade. It supports the following frequency bands: Bands 3, 5, 8, 20.

HLK-N10 is a 44-pin LCC packaged surface-mount module, which is embedded in various data transmission products through pads, providing rich hardware interfaces for communication between the module and the customer's main board.

HLK-N10 adopts power-saving technology, and the current power consumption is lower than 1uA in Power Saving Mode (PSM).

HLK-N10 is a high-performance, low-power consumption, multi-band NB-IoT wireless communication module. Its size is only 15.8 × 17.7 × 2.0mm, which can meet the needs of terminal devices for small-size module products to the greatest extent, and at the same time effectively help customers reduce product size and product cost.

HLK-N10 provides rich external interfaces, embeds various communication protocol stacks, and supports China Mobile OneNET and China Telecom IoT platforms, providing great convenience for customers' applications. It can meet the needs of IoT applications, including electricity meters, gas meters, water meters, smoke detectors, street lights, manhole covers, fire hydrants, agriculture and environmental monitoring, etc.

	Type	Description
	Product type	4G/3G/2G/NB module
	Manufacturer	Shenzhen Hi-Link
	Brand	Hi-Link
	Universal package	LCC 贴片封装
	Port	UART + USIM 卡接口（支持 1.8/3.0V）
	Installation mode	SMT 贴片焊接
	Operating temperature	-40℃ ~ +85℃
	Length * width * height	15.8 × 17.7 × 2.0mm

Display similar products ( 0 )
